PLC Control Robotic Bag Unloading Equipment System For Plastic Pellets 300 Bags/Hour

PLC Control Robotic Bag Unloading Equipment System For Plastic Pellets 300 Bags/Hour

Brand Name:	MACHTECH

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE ISO

Capacity:

Depends On The Specific System And Customer Needs

Control System:

PLC

Installation:

On-site Installation By Professional Technicians

Safety Features:

Emergency Stop Button, Safety Interlock System

Material:

Stainless Steel

Operation Mode:

Automatic

Power Source:

Electricity

Product Type:

Industrial Equipment

Loading Method:

Pneumatic Or Mechanical

Maintenance:

Regular Maintenance Required For Optimal Performance

Unloading Method:

Gravity Or Pneumatic

Application:

Unloading Raw Materials From Trucks Or Containers

Conveying Distance:

Customizable

Conveying Speed:

Adjustable

Dust Collection System:

Included

Installation Method:

Fixed On Ground

Unloading Mode:

Automatic

Power Supply:

380V/50Hz

Conveying Method:

Pneumatic

Highlight:

Plastic Pellets Bag Unloading System

,

PLC Control Robotic Bag Unloading Equipment

,

300 Bags/Hour Bag Unloading Equipment

Product Description

Robotic Bag Unloading System for Plastics

Key Specifications

Throughput: ≥300 bags/hour (2-cell system, ≥150 bags/h per unit)
Control System: Programmable Logic Controller (PLC)
Contact Surfaces: Stainless Steel 304
Recognition: Spherical/positional bag detection via 3D vision
Error Prevention: RFID/QR code verification

System Description

This dual-robot unpacking system handles plastic raw material bags with three operational modes:

Full-Pallet Breakdown: Layer-by-layer unloading
Single-Layer Separation: Selective layer removal
Individual Bag Processing: Isolated bag handling

Component Brands

Core Component	Brand/Specification
Robotic Arm	Kawasaki
Base Frame	Mach Tech
3D Vision System	Mech-Mind
Grippers Tool	MachTech
Safety Fencing	Mach Tech

Typical Applications

Full-pallet depalletizing
Selective layer removal
Single-bag precision pickup

Plastics Industry Applications

Compounding: Automated feeding of PP/PE pellets
Masterbatch: Additive bag unloading
Recycling: Post-consumer bale breakdown

Performance Notes

Throughput based on standard 25kg woven PP bags. Variables affecting speed include bag material thickness, stacking pattern consistency, and ambient dust levels.
