| Brand Name: | MACHTECH |
| Price: | US$150,000.00 - 350,000.00 |
| Payment Terms: | MoneyGram,Western Union,T/T,D/P,D/A,L/C |
| Structure | Vertical |
|---|
This advanced automatic batching and weighing system provides comprehensive management and control of the entire rubber mixing process.
| Carbon black scale weighing range | 30/50/200/200 kgs |
| Oil scale weighing range | 10/20/30/40/50 kgs |
| Rubber scale weighing range | 100/150/200/300/400 kgs |
| Powder scale accuracy | Static ≤ ±0.1% F.S, Dynamic ≤ ±0.2% F.S. |
| Weighing cycle time | ≤90-120s/batch |
| Oil injection pressure | 2-6 Mpa |
| Oil conveying temperature | 0-85ºC |
| Processing cycle time | ≤20s |
| Dust content after removal | ≤8mg/m³ |
| System noise level | <75dB |
| Installed capacity | 50-100kW/set |
Our Automatic Batching System incorporates advanced German and British technologies, developed by our R&D team for handling powders, pellets, bulk materials, and liquids. The system integrates five key components: powder handling, oil handling, bulk material processing, dust removal, and comprehensive control. The intelligent management system combines modern information technology with production control, enabling complete process automation, quality tracking, and improved product consistency. Widely adopted in rubber, polymer, silicone, and plastic industries, this system is compatible with various mixer types and has proven reliability in domestic and international applications.
