Automatic Carbon Black Weighing And Batching Equipment Customized

Brand Name:	MACHTECH
Price:	US$200,000.00 - 450,000.00
Payment Terms:	MoneyGram,Western Union,T/T,D/P,D/A,L/C

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO, CE

Structure:

Chemical Weighing

Type:

Customized

Capacity:

Depends On The Specific System And Customer Needs

Control System:

PLC

Installation:

On-site Installation By Professional Technicians

Safety Features:

Emergency Stop Button, Safety Interlock System

Material:

Stainless Steel

Operation Mode:

Automatic

Power Source:

Electricity

Product Type:

Industrial Equipment

Loading Method:

Pneumatic Or Mechanical

Maintenance:

Regular Maintenance Required For Optimal Performance

Unloading Method:

Gravity Or Pneumatic

Application:

Unloading Raw Materials From Trucks Or Containers

Conveying Distance:

Customizable

Conveying Speed:

Adjustable

Dust Collection System:

Included

Installation Method:

Fixed On Ground

Unloading Mode:

Automatic

Power Supply:

380V/50Hz

Conveying Method:

Pneumatic

Packaging Details:

Standard Seaworthy Packaging

Highlight:

carbon black weighing and batching equipment

customized weighing and batching equipment

Product Description

Automatic Batching Machine - Carbon Black Weighing and Batching Equipment

Product Specifications

Attribute	Value
Structure	Chemical Weighing
Type	Customized

System Functions

Raw material Management
Production Schedule Management
Production Recipe Management
Mixing Optimization Function
Data Report Management
Dynamic Real Time Monitoring
Quality Tracing Function
System Alarm Prompting Function
Fault Diagnosis Analysis
Remote Monitoring Function

Technical Parameters

Carbon black scale weighing range	30/50/200/200 Kgs
Oil scale weighing range	10/20/30/40/50 Kgs
Rubber scale weighing range	100/150/200/300/400 Kgs
Powder scale weighing accuracy	Static≤±0.1% F.S, dynamic≤±0.2% F.S.
Weighing cycle time	≤90-120s/batch
Carbon black pneumatic conveying capacity	3-15t/h
Oil injection pressure	2-6 Mpa
Oil conveying temperature	0-85ºC
Processing cycle time	≤20s
Dust contents in tail air	≤8mg/m³
System equipment noise	<75dB
Installed capacity	50-100kW/set

Key Features

Comprehensive process management with remote monitoring and after-sales support
Optimized rubber mixing through integral calculation of time, temperature, energy, rotation speed and pressure parameters
High weighing accuracy using high-resolution sensors and weighing display instruments
Reliable performance with imported or joint venture components
Bilingual Chinese-English interface with multi-area display and simple operation
Energy efficient field bus working system with PLC substations
Automatic system diagnostics with alarm location and solution prompts
Optimized dust removal and recovery system for clean operation
Modern information technology integration for production management
Flexible system design adaptable to various factory layouts
