Automated Material Handling Solution
>
Customized Automatic Weighing Dosing Batching System For Rubber Industry

Customized Automatic Weighing Dosing Batching System For Rubber Industry

Brand Name: MACHTECH
Price: US$100,000.00 - 300,000.00
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Detail Information
Place of Origin:
China
Certification:
CE, ISO
Type:
Customized
Capacity:
Depends On The Specific System And Customer Needs
Control System:
PLC
Installation:
On-site Installation By Professional Technicians
Safety Features:
Emergency Stop Button, Safety Interlock System
Material:
Stainless Steel
Operation Mode:
Automatic
Power Source:
Electricity
Product Type:
Industrial Equipment
Loading Method:
Pneumatic Or Mechanical
Maintenance:
Regular Maintenance Required For Optimal Performance
Unloading Method:
Gravity Or Pneumatic
Application:
Unloading Raw Materials From Trucks Or Containers
Conveying Distance:
Customizable
Conveying Speed:
Adjustable
Dust Collection System:
Included
Installation Method:
Fixed On Ground
Unloading Mode:
Automatic
Power Supply:
380V/50Hz
Conveying Method:
Pneumatic
Packaging Details:
Seaworthy Packing
Highlight:

customized automatic weighing system

,

chemical weighing system for rubber

,

rubber industry weighing dosing batching system

Product Description
Automatic Chemical Weighing Dosing Batching System for Rubber Industry
Product Specifications
Type Customized
Main Technical Parameters
Number of applicable dosing chemicals 8-48 kinds
Weighing range of electronic scale 10-50kgs
Weighing accuracy of electronic scale (static) ≤±0.1% F.S
Weighing accuracy of electronic scale (dynamic) ≤±0.15% F.S
Weighing accuracy of electronic scale (accumulative) ≤±0.2% F.S
Gradient of weighing display instrument 1g, 2g, 5g
Dosing cycle time and productivity 240-360 bags/shift
Dust contents in tail air after dust removal system ≤8mg/m³
System equipment noise <75dB
Installed capacity 15-25kW/Set
Key Features
  • Remote management and control capability with after-sales support for improved operational management
  • High-resolution electronic scale and weighing instruments ensure precise measurement accuracy
  • Multi-station simultaneous weighing and dosing with capacity of 200-600 bags per shift
  • Premium imported components and joint venture parts guarantee system stability and reliability
  • Field bus working system with PLC substations for automatic condition monitoring and troubleshooting
  • User-friendly Chinese-English interface with multi-area process display and monitoring functions
  • Comprehensive system diagnostics with alarm location and troubleshooting prompts
  • Energy-efficient design with safety interlocking protection measures
  • Advanced dust removal system with bag filters prevents material waste and maintains clean environment
  • Flexible layout options (1 or 2 story) adaptable for 8-48 raw material types
